YWPL — High-Efficiency Backward-Curved Plug-In Fan

Midi Industrial is a renowned Asian manufacturer of HVAC fans and building ventilation fans for engineering projects - engineered to fuse aerodynamics, motor technology and intelligent control.

No scroll housing around this wheel. The YWPL is a backward-curved plug-in fan, meaning the impeller and drive assembly sit straight inside the AHU or fresh-air cabinet, mounted to the fan section rather than delivered as a cased blower. That saves the space a separate scroll and casing would take, and the airstream enters the wheel directly from the plenum side.

How it sits inside the unit
The backward-curved wheel is the efficient profile for medium-to-high pressure duties. On a plug fan there is no volute to convert velocity to pressure the way a cased centrifugal does, so the surrounding cabinet becomes part of the air path; clean casing sections and good inlet geometry matter when you fix the size. Because there is no separate casing, the fan performance also depends on the cabinet's inlet and outlet geometry, and a smooth approach section keeps the wheel working near its design point. The cartridge can be pulled out for service without opening the ductwork, which is why these units are popular inside supply and return air handlers. Wheel diameters run 12.4 to 49 inches, airflow up to 29,100 m3/h against 0 to 2,980 Pa. Midi Industrial lists the YWPL among its central air-conditioning fan options for equipment makers who build fans into their own cabinets.

Where it's used
Central air-conditioning units, fresh-air handlers and air handling cabinets in commercial buildings, cleanrooms and industrial ventilation equipment. Before ordering, confirm the available plenum section and the inlet side clearance; send the airflow and static-pressure point so the wheel size can be matched to the cabinet.

Impeller Diameter: 12.4-49 in
Air Volume: Up to 29100 m³/h
Pressure: 0-2980 Pa
