SYDS — Single Inlet Forward Multi-Blade Centrifugal Fan

Midi Industrial is a renowned Asian manufacturer of HVAC fans and building ventilation fans for engineering projects - engineered to fuse aerodynamics, motor technology and intelligent control.

One air inlet instead of two - that is the main difference between the SYDS and the double-inlet SYD. The SYDS Single Inlet Forward Multi-Blade Centrifugal Fan uses a belt drive for central air-conditioning units where the cabinet is narrow, or where the fan is mounted in a side section rather than a wide central plenum. It covers 700 to 50,000 m3/h over 180 to 1000mm wheels at pressures up to 1,300 Pa.

What you get for the footprint
With air entering only one side, the overall casing is shallower than a double-inlet fan of similar duty, which can save space inside an AHU or a rooftop unit section. The forward multi-blade wheel stays aimed at volume over pressure - supply and return air duties at low to medium resistance. The belt drive lets speed be matched through pulley ratios, and the motor stays clear of the airstream. Service means checking belt tension and replacing worn belts when needed; the motor and pulleys remain accessible from the side of the unit. For an HVAC fan manufacturer assembling smaller central air-conditioning boxes, Midi Industrial positions this as the single-inlet option on the same belt-driven platform as the larger double-inlet models.

Choosing a size
Typical homes for the SYDS are mid-size central air-conditioning cabinets, fresh-air handlers and ventilation boxes in offices, shops and light industrial spaces. If casing depth is tight, the single-inlet layout is the reason to pick it over a double-inlet equivalent; give the airflow and static pressure so the wheel and pulley size can be selected.

Impeller Diameter: 180-1000mm
Air Volume: 700-50000 m³/h
Pressure: 0-1300 Pa
Drive Type: Belt drive
