If you're sizing a compact fresh-air unit or a small AHU, the YUWB is the plug fan made for that end of the range. The wheel runs 250-400 mm and moves 600-8,000 m3/h against pressures up to 2,000 Pa - a sensible match for medium rooms and light commercial boxes, without forcing a bigger assembly into a tight cabinet. There is no scroll housing around the wheel; the motor and wheel sit straight inside the air handling unit, and the cartridge lifts out for service without disturbing the ductwork on either side.
How the EC drive works
The motor and speed controller form one integrated block, so no external VFD cabinet needs to be supplied or wired. Signals accepted are VSP, 4-20mA, PWM and 485, letting the fan follow a thermostat, CO2 sensor or BMS demand and change speed with the actual load in the room rather than running flat out all day. Drive is direct: no belt, no pulley, no belt tension to maintain, so the wearing-parts list stays short. Motor power spans 500W-3500W, insulation grade F, working temperature -25 C~40 C.
Where it lands
Fresh-air units and air handling units are the standard fit, most often in offices, shops, classrooms and light commercial plant rooms. Before locking a size, confirm the cabinet depth and available section around the unhoused cartridge; send the airflow and static-pressure target and we can match wheel and motor.
Diameter: 250-400mm
Air Volume: 600-8000 m³/h
Pressure: 0-2000 Pa
Motor Power: 500W-3500W
Control: VSP/4-20mA/PWM/485
Insulation Grade: F
Working Temp: -25℃~40℃
YUWB is the smaller EC plug fan for compact fresh-air units and AHUs, with a 250-400 mm wheel and 600-8,000 m3/h. The integrated EC drive and pull-out cartridge make it easy to install and service.
